Slant Bed CNC Machine Tools CK5055 Export To Russia

Slant Bed CNC Machine Tools is a high precision, high efficient automated machine tool for metal processing. Slant bed CNC Machine can be equipped with multi-station turret or power turret to get a wide range of process performance, it can process linear cylinders, diagonal cylinders, arcs and various complex workpieces, and play a good economic effect in mass production of complex parts. The cross-sectional area of the slant bed CNC lathe is larger than that of the flat bed of the same specification, that is, this slant bed lathe is stronger against bending and torsion resistance.

This Russia customer needed a CNC turning lathe. He sent us his request of the slant bed machine size, and we recommended Slant Bed CNC Machine CK5055 for him. He was also very agree with us and requested the customized configuration after the detail quotation of the Slant Bed Machine was confirmed. And we sent him the appearance, he was satisfied with the Slant Bed CNC Lathe.

After the Slant Bed CNC lathe Machine Tools completed, he told me no need to come to check. So we sent him the Slant Bed CNC Machine operate video and the completed workpieces. He was very satisfied and paid the balance immediately.

Slant Bed CNC Machine Tools Specifications

Item	Unit	Specifications
Maximum turning diameter of the bed	mm	450
Maximum turning diameter on the pallet	mm	150
Maximum processing length	mm	580
Maximum spindle speed	r/min	3800
Machine tool dimensions (L × W × H)	mm	2300/1700*1500
Rail width	mm	355
Machine weight	Kg	2100

Slant Bed CNC Machine Tools Features

• High rigidity slant bed and reasonable structure.
• The servo motor is directly connected with the lead screw through high torque and low inertia elastic coupling to ensure positioning accuracy and repeat positioning accuracy.
•  CNC lathe machine tool basic parts are highly rigid and ensure the stability of CNC machine for sale for long-term use.

Slant Bed CNC Machine Tools configuration

• 980TC3 system bus system
• Row Tool
• Hydraulic collet
• kw servo main motor
• Spindle unit
• X/Z Taiwan linear Rail

About HAISHU Machinery

As the professional CNC machine designer and manufacturer, Taian HAISHU Machinery Co., Ltd (Haishu Machinery) is the high-tech enterprise specialized in CNC machine development, production, sales and service since 2001.  Our high quality and innovative products include CNC lathe,Slant Bed CNC Machine ,CNC milling machine, CNC machining center, CNC turn-mill machine, CNC tool grinding machine, CNC pipe threading lathe, CNC wood lathe, stone CNC machine, CNC root canal file grinder and custom CNC equipment for special requirements. HAISHU Machinery is not only manufacturing best quality CNC machine products but also providing custom product design and after sale services. Welcome to contact us for detailed information.

Technical Application Of CNC Lathe Machine Tools

CNC lathe machine tools are the widely used lathes with a program control system that allows the CNC lathe machine to move and process parts based on programmed procedures. CNC machine tools combine the latest technologies in machinery, automation, computer, measurement, microelectronics and a variety of sensors, etc. The sensors used in the CNC lathe machine mainly include photoelectric encoders, linear encoders, proximity switches, temperature sensors, Hall sensors, and currents. Sensors, voltage sensors, pressure sensors, liquid level sensors, resolvers, inductive synchronizer, speed sensors, etc., are mainly used to detect position, linear displacement and angular displacement, speed, pressure, temperature and so on.

Requirements for sensors on CNC lathe machine tools

1) High reliability and strong anti-interference;

2) meet the requirements of accuracy and speed;

3) Easy to use and maintain, suitable for machine tool operating environment;

4) Low cost.

The requirements of different types of CNC lathe machine tools are not the same. Generally speaking, large machine tools require high speed response, and medium and high precision CNC lathe are mainly required.

Application of inductive synchronizer

Inductive synchronizers are made using the principle that the mutual inductance of two planar windings varies with position. The save function is to convert the angular or linear displacement into the phase or amplitude of the induced electromotive force, which can be used to measure the linear or angular displacement. According to its structure, it can be divided into two types: linear and rotary. The linear induction synchronizer consists of a fixed length and a sliding ruler. The fixed length is mounted on the CNC lathe machine bed, the slide is mounted on the moving part and moves with the worktable; the rotary induction synchronizer stator is a fixed disc and the rotor For rotating discs. The inductive synchronizer has the advantages of high precision and resolution, strong anti-interference ability, long service life, simple maintenance, long-distance displacement measurement, good process ability and low cost. Rotary inductive synchronizers are widely used in turntables for machine tools and instruments, as well as in various rotary servo control systems.

CNC Turning Milling Drilling Boring Machine CK0640 Exported to Malaysia

CNC Turning Milling Drilling Boring Machine (also called CNC Turning Milling Machine, CNC Turning Center) CK0640 designed and manufactured by HAISHU Machinery is capable of both rotating-workpiece operations like turning and rotating-tool operations such milling and drilling.  That is to say, The CNC Turning Milling Drilling Boring Machine can process turning, milling and drilling of complex workpieces in one operation. This CNC Machine is suitable for high accuracy and conformance requirements for small and medium-size disk and short axle parts.

This time the Malaysia old customer needed a CNC machine with multifunction. He sent me his workpiece drawings directly. After the engineer checked, the workpiece not only needed Turning and Milling function also requested Drilling and Boring, because the size was small, so we decided to customized a special machine for him. He was very glad to hear we can customize.

We chose a suitable size CNC lathe CK0640A for him and depended on the drawings our engineer add the configuration of all the functions. Then according to the configuration, we chose the suitable level system. Finally, we named it CNC turning lathe CK0640. And sent the detail quotation and configuration to customer. He was satisfied and paid the deposit.

After the CNC lathe machine completed, he told me no need to come to check. So I sent him the CNC machine’s operate video. He paid the balance immediately.

CNC Turning Milling Drilling Boring Machine CK0640 Specifications

Items	Unit	Specifications
Max.swing over the bed	mm	Φ280
Max.swing over carriage	mm	Φ100
Max. length of the work piece	mm	200
Spindle head form		A2-5
Spindle Bore	mm	Φ48
Range of spindle speed	r/min	0-3000  Positive & negative
Power of the main drive motor	Kw	3
Turret form		4-position electric turret
Y-axis		Optional
Overall dimensions(L×W×H)	mm	1860×1300×1580
Net weight	Kg	1000

CNC Turning Milling Drilling Boring Machine CK0640 function and Main purpose

◆With：Turning, Milling, Drilling, Tapping function.

◆Spindle motor: servo control, C axis function, positive & negative stepless variable speed.

◆Spindle dynamic synchronous belt transmission, with the function of spindle brake.

◆The CNC machine equipped with X / Z milling head, it can mill End groove and cylindrical groove;

◆Hydraulic chuck and collet can be replaced

◆X/Z -axis line rail, stainless steel shield protection.

◆Z-axis screw middle position.

◆Automatic oil lubrication.

◆Machine tool for new protection.
The CNC machine can be widely used in metal parts finishing, which can realize external circular, inner hole, side hole, end face, side flat, circular groove, groove, spiral groove, cone, sphere, etc and automatic processing of various kinds of a metric inch inside-outside thread.

CNC Turning Milling Drilling Boring Machine CK0640 configuration

★ CNC System：GSK980TDc

★ Hydraulic Chuck

★ Hydraulic collet

★ 2 milling powerhead

★ Y-axis function.

★ Feeder.

★ Parts collector.

About HAISHU Machinery

As the professional CNC machine designer and manufacturer, Taian HAISHU Machinery Co., Ltd (Haishu Machinery) is the high-tech enterprise specialized in CNC machine development, production, sales and service since 2001. We have more than 30 professional talented CNC experts and more than 12,000 square meters manufacturing factory.  More than 16 series 80 kinds of CNC machines and related parts had been manufactured to satisfy your pumping requirements. Our high quality and innovative products include Chinese CNC Lathe, CNC milling machine, CNC machining center, CNC turn-mill machine, CNC tool grinding machine, CNC pipe threading lathe, CNC wood lathe, stone CNC machine, CNC root canal file grinder ,CNC Turning Milling Drilling Boring Machine and custom CNC equipment for special requirements.HAISHU Machinery is not only manufacturing best quality CNC machine products but also providing custom product design and after sale services. Welcome, contact us for detailed information.

The Basic Composition Of CNC Machine Tools

The basic components of CNC machine tools include machining program carriers, numerical control devices, servo drives, machine tool bodies and other auxiliary devices. The basic working principle of each component is outlined below.

Processing program carrier

When the CNC lathe is working, it is not necessary for the worker to directly operate the machine tool. To control the CNC machine tools, the machining program must be programmed. The part processing program includes the relative motion trajectory of the tool and the workpiece on the machine tool, the process parameters (feedrate spindle speed, etc.) and auxiliary motion. The part processing program is stored in a program carrier, such as a punched paper tape, a cassette tape, a floppy disk, etc., with a certain format and code, and the program information is input to the CNC unit through the input device of the numerical control machine tool.

CNC device

The numerical control device is the core of the CNC machine tools. Modern numerical control devices are all in the form of CNC (Computer Numerical Control). This CNC device generally uses multiple microprocessors to implement numerical control functions in the form of programmed software. Therefore, it is also called Software NC. The CNC system is a position control system that interpolates the ideal motion trajectory based on the input data and outputs it to the parts required to machine the actuator. Therefore, the numerical control device mainly consists of three basic parts: input, processing and output. All of this work is reasonably organized by the computer’s system program, allowing the entire system to work in harmony.

1) Input device: The numerical control command is input to the numerical control device, and according to different program carriers, there are different input devices. There are mainly keyboard input, disk input, CAD/CAM system direct communication mode input and DNC (direct digital control) input to the upper computer. There are still many systems that still have the paper tape input form of the optical reader.

(1) Paper tape input method. The paper tape photoelectric reader can be used to read the part program, directly control the movement of the machine tool, or read the contents of the paper tape into the memory, and control the movement of the machine tool by using the part program stored in the memory.

(2) MDI manual data input method. The operator can use the keyboard on the operation panel to input the instructions of the machining program, which is suitable for relatively short programs.

In the control device edit state (EDIT), the machining program is input into the memory and stored in the memory of the control device. This input method can be used repeatedly. This method is generally used for manual programming.

On the numerical control device with session programming function, different menus can be selected according to the prompts on the display, and the machining program can be automatically generated by inputting the relevant size numbers by means of human-machine dialogue.

The DNC ​​direct numerical control input mode is adopted. The part program is saved in the upper computer, and the CNC system receives the subsequent block from the computer while processing. The DNC method is mostly used for complex workpieces designed with CAD/CAM software and directly generates part programs.

2) Information processing: the input device transmits the processing information to the CNC unit, and compiles it into a piece of computer-recognizable information. The information processing part gradually stores and processes the information according to the control program, and then sends the position and speed command to the servo through the output unit. System and main motion control section. The input data of the CNC system includes contour information of the part (starting point, end point, straight line, arc, etc.), machining speed and other auxiliary machining information (such as tool change, shifting, coolant switch, etc.). The purpose of data processing is to complete the insertion. Preparation before the complement operation. The data processing program also includes tool radius compensation, speed calculation, and processing of auxiliary functions.

3) Output device: The output device is connected to the servo mechanism. The output device receives the output pulse of the arithmetic unit according to the command of the controller, and sends it to the servo control system of each coordinate, and drives the servo system through power amplification, thereby controlling the machine tool to move according to the specified requirements.

Servo and measurement feedback system

The servo system is an important part of the CNC machine tools, which is used to realize the feed servo control and spindle servo control of CNC machine tools. The function of the servo system is to accept the command information from the numerical control device, and then convert it into linear displacement or angular displacement motion of the machine tool by power amplification and shaping. Since the servo system is the last link of the CNC machine tools, its performance will directly affect the technical indexes such as the precision and speed of the CNC machine tool. Therefore, the servo drive device of the CNC machine tools is required to have good fast response performance, and accurately and sensitively track the numerical control device. The digital command signal is sent and the instructions from the numerical control device can be faithfully executed to improve the dynamic follow-up characteristics and static tracking accuracy of the system.

The servo system consists of two parts: the drive unit and the actuator. The drive unit is composed of a spindle drive unit, a feed drive unit, a spindle servo motor, and a feed servo motor. Stepper motors, DC servo motors and AC servo motors are commonly used drives.

The measuring component detects the actual displacement value of each coordinate axis of the CNC machine tools and inputs it into the numerical control device of the machine tool through the feedback system. The numerical control device compares the actual displacement value returned by the numerical control device with the command value and outputs the set value to the servo system. The required displacement command.

Machine body

The machine host is the main body of the CNC machine. It includes mechanical components such as bed, base, column, beam, slide, table, headstock, feed mechanism, tool holder and automatic tool changer. It is the mechanical part that automatically performs various cutting operations on CNC machine tools. Compared with traditional machine tools, the main body of CNC machine tools has the following structural features:

1) Adopt a new machine tool structure with high rigidity, high shock resistance and small thermal deformation. Generally, the stiffness and shock resistance of the machine tool main body are improved by improving the static stiffness of the structural system, increasing the damping, adjusting the quality of the structural member and the natural frequency, so that the machine tool body can adapt to the need for the CNC machine tool to continuously and automatically perform the cutting process. Measures such as improving machine structure layout, reducing heat generation, controlling temperature rise, and using thermal displacement compensation can reduce the impact of thermal deformation on the machine tool host.

2) The high-performance spindle servo drive and feed servo drive are widely used to shorten the drive chain of CNC machine tools and simplify the structure of the machine tool drive system.

3) Adopt high transmission efficiency, high precision, gapless transmission and moving parts, such as ball screw nut pair, plastic sliding guide, linear rolling guide, static pressure guide and so on.

CNC machine tool auxiliary device

The auxiliary device is the necessary device to ensure the full play of the functions of the CNC machine tool. The commonly used auxiliary devices include: pneumatic, hydraulic device, chip removal device, cooling, lubrication device, rotary table and numerical control indexing head, protection, lighting, etc. Auxiliary device

About HAISHU Machinery

Taian Haishu Machinery Co., Ltd. is the professional CNC machine designer and manufacturer dedicated in supplying automobile wheel production and repair solutions to worldwide customers. We have been always worked hard to become the leader in designing and manufacturing CNC lathes since 2001.   We have more than 30 talented experts and more than 12,000 square meters factory. Our innovative, high-quality products include wheel CNC machine, wheel repair machine, brake drum lathe and customized CNC lathe machine.

Small Slant Bed CNC Lathe CK4030 Export to Peru

Small slant bed CNC lathe CK4030 is a high-precision, high-efficiency automatic machine tool. Slant bed CNC lathe can be equipped with multi-station turret or power turret. The slant bed machine tool has a wide range of process performance that can process linear cylinders, diagonal cylinders, arcs and various complex workpieces such as threads, slots, worms, with linear interpolation, circular interpolation Compensate for various compensation functions and play a good economic effect in mass production of complex parts. The cross-sectional area of the slant bed CNC lathe is larger than that of the flatbed of the same specification, that is, this slant bed lathe is stronger against bending and torsion resistance.

Our Peru wanted to buy a CNC lathe. According to the request of machine size, he needed a small CNC lathe. At the same time, he also requested high-precision, high-efficiency, so we suggested Small slant bed CNC turning center CK4030 for him. After checked the specification and processing video of the small slant lathe, He confirmed the CNC lathe was suitable for him and asked for PI. A few days later, he arranged the deposit.

After the Small slant bed, CNC lathe CK4030 was completed, We invited him to acceptance and test. He expressed that no need to come and he was very confident with both our company and our machines. So we sent him the slant bed CNC lathe operate video and detail pictures. He was very satisfied to cooperate with us.

Small Slant Bed CNC Lathe CK4030 Specification

Item	Unit	Specifications
Maximum turning diameter of the bed	mm	400
Maximum turning diameter on the pallet	mm	150
Maximum processing length	mm	300
Spindle head form		Spindle unit
Spindle through hole diameter	mm	49
Rail width	mm	250
Total length of guide rail	mm	640
X/Z axis repeat positioning accuracy	mm	0.001
X-axis (horizontal) maximum stroke	mm	300
Z axis (horizontal) maximum stroke	mm	300
Machine tool dimensions (L × W × H)	mm	1700*1200*1600
Machine weight	Kg	1300

Small slant bed CNC lathe CK4030 Features

1. High rigidity slant bed structure, reasonable structure, and high rigidity.
2. The servo motor is directly connected with the lead screw through high torque and low inertia elastic coupling to ensure positioning accuracy and repeat positioning accuracy.
3. High rigidity.  CNC lathe machine tool basic parts are highly rigid and ensure the stability of CNC machine for sale for long-term use.

Small slant bed CNC lathe CK4030 configuration

• 1.980TC3 system bus system
• Row Tool
• Hydraulic collet
• 4.4kw servo main motor
• Spindle unit
• X/Z Taiwan linear Rail

About HAISHU Machinery

Taian HAISHU Machinery Co., Ltd (Haishu Machinery) mainly engaged  CNC lathe, CNC milling machine, Vertical Machining Center, Small slant bed CNC lathe,CNC turn-mill machine, CNC tool grinding machine, CNC pipe threading lathe, CNC wood lathe, stone CNC machine, CNC root canal file grinder, custom CNC equipment and other products research and development, production. The company has a technology research and development center and product supervision and testing center. Through years of hard work, we have developed into a famous machine tool enterprise in China.

Our company’s products are sold well in the country with stable performance and reliable quality and are exported to more than 50 countries. The company pursues a brand-name, high-grade quality strategy, and has been rated as a Contract-honoring and credit-worthy enterprise by the Provincial Industrial and Commercial Bureau. We will adhere to the “integrity, initiative, responsibility, cooperation” policy, abide by the “customer’s success is our success” business philosophy, to provide you with advanced products, perfect after-sales service.

CNC Lathe Machining Center |CNC Turning Center|CNC Lathe CK4030

Small Vertical Machining Center VMC500 Delivered To Australia

Small vertical machining center VMC500 is a semi-closed loop vertical machining center controlled by X, Y and Z three-axis servo motor. The three axes are steel ball rolling linear guides. The guide rail has a large load, wide span and high precision. The structure and external dimensions are compact and reasonable. The main shaft is the servo motor driven by the synchronous belt. The small CNC machining center can realize the clamping of complex parts such as various discs, plates, shells, cams and molds. Milling, boring, expansion, hinge, rigid tapping and other processes are suitable for the production of multi-variety, small and medium-sized products, it can also process complex products and high-precision parts. The vertical machining center can be equipped with a fourth rotating shaft to meet the processing requirements of special parts.

The Australia customer is and old customer of ours. This time he needed Vertical Machining Center. According to the request of table size, he needed a small size, We chose Small vertical machining center VMC500 for him. After checked the parameter and configuration of the Vertical Machining Center VMC500, He confirmed the machining center was suitable for him and asked for PI. A few days later, he arranged the payment.

After the Small vertical machining center, VMC500 completed, We invited him to accept the test. Because he already knew our machine quality. He said that he didn’t have time and was very comfortable with our machines. So we sent him the CNC Machining Center VMC650 operate video and detail pictures. He was very happy to cooperate with us again.

Small vertical machining center VMC500 Features

• High rigidity. The vertical milling center adopts the bed-type machining center structure. The vertical machining center for sale consists of a base, slide seat, work table, column, and headstock. The main basic parts are analyzed by finite element structure, the structure is reasonable and the rigidity is large; all machine tool castings are hot. Aging treatment, precision has long-term stability.
• The vertical milling center manufacturers adopt high-speed, high-precision and rigid Taiwan spindle unit. The spindle material is made of high-performance alloy steel. The P4 high-speed precision bearing for the spindle is used, and the high-speed grease is used. The spindle speed reaches 8000 rpm and the spindle radial runout is less than 0.008/300.
• X, Y, Z direction feed adopts C3 grade double nut preloaded precision ball screw. The servo motor is directly connected with the lead screw through high torque and low inertia inlet elastic coupling, and the lead screw support adopts pretensioning structure. This CNC machining center can eliminate the backlash of the transmission and compensate for the influence of thermal deformation on the precision of small CNC machining center during long-term operation to ensure the positioning accuracy and repeat positioning accuracy.

Small vertical machining center VMC500 Installation Requirements

1. Power supply and environmental requirements.

1.1 Power supply voltage: 380V ± 10%

1.2Power frequency: 50HZ ± 1%, three-phase

1.3Gas source: 6kg/cm2 After proper drying

2.Environmental conditions for use.

2.1Relative humidity: ≤80%

2.1Ambient temperature: 0°C-40°C

2.3Air medium: non-corrosive medium

2.4 Light: adequate, well ventilated

2.5 CNC machining center for sale works stable for a long time under the above working conditions.

3.Installation site conditions

3.1Not affected by external vibration.

3.2Not affected by corrosive gases.

3.3Avoid direct sunlight on a high-speed machining center.

3.4Avoid direct contact with outside wind, air and temperature regulation of cold and hot air.

3.5Avoid setting heat sources such as heating near the small vertical machining center.

3.6Reduce dust (avoid castings, welding, sheet metal workshops, etc.).

About HAISHU Machinery

Taian HAISHU Machinery Co., Ltd (Haishu Machinery) mainly engaged  CNC lathe, CNC milling machine, Vertical Machining Center, Small vertical machining center,CNC turn-mill machine, CNC tool grinding machine, CNC pipe threading lathe, CNC wood lathe, stone CNC machine, CNC root canal file grinder, custom CNC equipment and other products research and development, production. The company has a technology research and development center and product supervision and testing center. Through years of hard work, we have developed into a famous machine tool enterprise in China.

Our company’s products are sold well in the country with stable performance and reliable quality and are exported to more than 50 countries. The company pursues a brand-name, high-grade quality strategy, and has been rated as a Contract-honoring and credit-worthy enterprise by the Provincial Industrial and Commercial Bureau. We will adhere to the “integrity, initiative, responsibility, cooperation” policy, abide by the “customer’s success is our success” business philosophy, to provide you with advanced products, perfect after-sales service.

•


What is CNC machine tool?

CNC machine tool is the computer numerical controlled (CNC) machine which can provide powerful, fast and precision workpiece cuts with indexable tools or drills.  one of the most widely used CNC lathe machines. The CNC lathe tool is mainly used for the inner and outer cylindrical surfaces of shaft parts or disc parts, the inner and outer conical surfaces of any taper angle, the complex inner and outer curved surfaces, the cylindrical and conical threads, etc., CNC machine tool can also be used for grooving, drilling, reaming and reaming. Holes and borings, etc.

The CNC machine tool automatically processes the machined parts according to the pre-programmed machining program. We process the machining process route, process parameters, tool trajectory, displacement, cutting parameters and auxiliary functions of the parts according to the instruction code and program format specified by the CNC machine tool, and then record the contents of the program list. On the control medium, hot sale CNC lathe is then inputted into the numerical control device of the CNC machine to direct the machine to machine the parts.

What are the characteristics of CNC machine tool?

CNC machine tool is the abbreviation of the digital control machine tool, which is an automatic machine tool with the program control system. The control system can logically process and decode the program with control code or other symbolic instructions to cause the machine to operate and machine the part.

Compared with ordinary machine tools, CNC machine tools have the following characteristics:

• High processing precision and stable processing quality;
• The multi-coordinate linkage can be performed to process parts with complex shapes;
• When the machined parts are changed, generally only need to change the NC program, which can save production preparation time;
• The machine tool itself has high precision and rigidity and can choose favorable processing amount, and the productivity is high (usually 3~5 times of ordinary machine tools);
• The degree of automation of the machine tool is high, which can reduce the labor intensity;
• The quality of the operators is high, and the technical requirements for maintenance personnel are higher.

The normal use of the CNC lathe must meet the following conditions: the power supply voltage fluctuation at the position where the machine is located is small, the ambient temperature is lower than 30 degrees, and the relative temperature is less than 80%.

Environmental requirements for CNC machine tool

The position of the machine tool should be away from the vibration source, and the direct sunlight and heat radiation should be avoided to avoid the influence of moisture and air flow. If there is a vibration source near the machine tool, anti-vibration grooves should be installed around the machine. Otherwise, it will directly affect the machining accuracy and stability of the machine tool, which will make the electronic components contact poorly, cause malfunction, and affect the reliability of the machine tool.

Power requirements for CNC machine tool

Generally, the CNC lathe is installed in the machine shop, which not only has large changes in ambient temperature, but also has poor operating conditions, and many kinds of electromechanical equipment, resulting in large fluctuations in the power grid. Therefore, the location of the CNC lathe requires strict control of the power supply voltage. Power supply voltage fluctuations must be within the allowable range and remain relatively stable. Otherwise, it will affect the normal operation of the CNC system.

Temperature conditions of CNC machine tool

The ambient temperature of the CNC lathe is less than 30 degrees, and the relative temperature is less than 80%. Generally speaking, the numerical control electric control box is internally provided with an exhaust fan or a cooling fan to keep the electronic components, especially the central processing unit, with a constant operating temperature or a small change in temperature difference. Excessive temperature and humidity will result in reduced life of the control system components and lead to increased failure. Increased temperature and humidity, increased dust can cause bonding on the integrated circuit board and cause short circuits.

Standardized use of CNC machine tool

When using the machine, the user is not allowed to arbitrarily change the parameters set by the manufacturer in the control system. The setting of these parameters is directly related to the dynamic characteristics of the various parts of the machine. Only the value of the gap compensation parameter can be adjusted according to the actual situation.

The user cannot change the machine attachment at will, such as using a hydraulic chuck that exceeds the specifications. When setting up the accessories, the manufacturer fully considers the matching of the parameters of each link. Blind replacement causes mismatches in the parameters of various links and even causes an accident that is not estimated.

The pressure of the hydraulic chuck, hydraulic tool holder, hydraulic tailstock, and hydraulic cylinder should be within the allowable stress range, and no increase is allowed.

Maintenance of CNC machine tool

CNC turning lathe is a high-precision, high-efficiency automated machine tool. Equipped with multi-station turret or power turret, the machine tool has a wide range of processing performance, can process linear cylinders, diagonal cylinders, arcs and various complex workpieces such as threads, slots, worms, with linear interpolation, arc Interpolated various compensation functions and played a good economic effect in the mass production of complex parts. The maintenance of the inclined bed CNC lathe is as follows:

In order to ensure the working accuracy of the inclined bed CNC lathe and prolong the service life, it is necessary to carry out reasonable maintenance work on the self-use slant bed CNC lathe. The quality of lathe maintenance directly affects the processing quality and production efficiency of the workpiece. When the Taiwanese Taichung Seiki CNC lathe runs for 500h, it needs to be level 1 maintained. The maintenance work of the inclined bed CNC lathe is mainly carried out by the operator and the maintenance worker cooperates. When servicing, the electric probe must be cut off first, and then maintained according to the maintenance contents and requirements.
